Hands-on Activity Clustering and Exploring the Periodic Table of Elements

Learning Objectives

After this activity, students should be able to:

• Understand the concept of clustering in machine learning.
• Apply clustering techniques to group elements based on their properties.
• Create rules to explain the rationale behind their chosen element clusters.
• Recognize the organizational patterns and trends in the periodic table of elements.
• Analyze the reasons for grouping elements together in specific regions of the periodic table.

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

NGSS: Next Generation Science Standards - Science

State Standards

Materials List

Each group needs:

• LEGO pieces (about 80-100 per group, all sizes/shapes)
• periodic table (one per group; can be printouts, in a textbook, or projected on the wall)
• large poster board (or space on the classroom wall)
• Clustering Criteria Handout

For the entire class to share:

• index cards/sticky notes
• markers/pens

Worksheets and Attachments

Pre-Req Knowledge

Familiarity with the concept of elements and grouping of similar/dissimilar items.

Introduction/Motivation

Think about your brain—it’s like a detective, always on the lookout for patterns. Whether it’s recognizing a melody or spotting shapes in the clouds, humans have a knack for noticing things that repeat and grouping things together. This isn’t a random coincidence; it’s an important part of understanding how the world works.

Being able to describe patterns is important in scientific, computational, and engineering thinking. A major component to that involves sorting, classifying, and clustering—key components of machine learning and Big Data. What patterns can we find when we sort objects in different ways? Today, we will explore this using LEGO pieces and the periodic table.

First, we’ll explore clustering using LEGO pieces. When creating groups of pieces, there are no right or wrong answers, a hallmark of machine learning clustering. Then, we’ll move on to exploring sorting and clustering with the elements of the periodic table.

Procedure

Background

Overview

As educators, we know that being able to find and describe patterns allows students to become more proficient in scientific, computational, and engineering thinking. A major component to that involves sorting, classifying, and clustering—key components of machine learning and Big Data. As teachers, we can pose the following question to our students to help drive this home: What patterns can we find when we sort objects in different ways? The question can be approached through an almost infinite variety of activities; this lesson focuses on two—LEGO pieces and the periodic table.

How can we improve our students’ ability to recognize and, more important, define patterns? Being able to explain the criteria behind a particular set of clusters is a large part of communicating in science, which should be one of our main goals as teachers: to get students ready to communicate not only what they know, but also how they know it, to others. This lesson serves as a training ground to improve those communication skills in explaining the reasons behind sorting decisions. It’s more than just putting things in groups; it’s about understanding the rules that govern those sorting decisions.

This lesson provides two opportunities to hone those skills in students. In the first, the lesson takes advantage of the ubiquity of LEGO bricks to provide a familiar playground to create those groups—without right or wrong answers, a hallmark of machine learning clustering. In the second, students switch gears to a more “classroom-content” focused activity that allows them to explore the elements of the periodic table, again without right or wrong answers.

Clustering and Machine Learning

Clustering is the process of grouping similar items or data points together based on shared characteristics or criteria, allowing for organization and analysis. Cluster analysis is a common task in machine learning. The program analyzes given data and sorts objects. There are many ways to cluster items. Clustering can be used as a first step in understanding a data set. It can also be used to identify patterns and relationships in data, thus allowing one to predict where a new piece of data might fit based on how its characteristics match those in existing groups.

The periodic table of elements is an example of clustering data. An element’s place in a row or column is determined by characteristics such as its size and chemical properties. Elements are also arranged into blocks, which show the location of their valence electrons. Dmitri Mendeleev looked at the characteristics of the known elements and grouped them to create a draft of the periodic table in 1869. Mendeleev used the clusters of elements to predict unknown elements, which were later discovered and found to have characteristics very similar to his predictions.

Most of the skills of computational thinking are explicitly discussed with the students throughout the walk-around/monitoring section of the activity, and again at the end during the whole-group discussion. The goal of the lesson is to start them working with the periodic table not as a declaration from on high, but as a method to organize patterns in the properties of elements.

Before the Activity

1. Gather materials.

• Create piles of 80-100 LEGO pieces for student groups. Optional: Place LEGO pieces in small bags for ease of distribution to groups.

2. Review vocabulary for the activity.

• Clustering – The process of grouping similar items or data points together based on shared characteristics or criteria, allowing for organization and analysis.
• Periodicity – The property of recurring patterns or trends in the periodic table, where elements exhibit similar behaviors or properties at regular intervals.
• Classification – The act of categorizing items or data into groups or classes based on shared characteristics or attributes.
• Subjectivity – The quality of being influenced by personal opinions, interpretations, or perspectives, rather than being solely objective or based on concrete facts.

During the Activity

1. Introduction (5 minutes)

1. Engage students by discussing the concept of clustering in machine learning and its purpose in grouping similar data points.
2. Relate the concept of clustering to the organization of the periodic table of elements, highlighting that elements are grouped based on similarities in properties.
3. Explain that clustering elements is subjective, with different criteria resulting in different groupings.

2. Clustering Activity Part 1 (15 minutes)

• Divide students into groups of 3 or 4.
• Give each student group a variety of LEGO pieces (the more varied the better, approximately 80-100 pieces). Reserve at least 3-4 pieces for each group.
• Tell students to group the LEGO pieces. Be explicitly vague about what this entails and mention that there are few rules—a group needs to have more than one piece, there must be more than one group, and the students must be able to provide justification for why the pieces are grouped as they are.



• When students have completed their groupings, give each student group the reserved pieces and ask them to place them into the existing groups, providing an explanation of each group’s criteria (this may be a full-group discussion).



3. Clustering Activity Part 2 (15 minutes)

1. Collect LEGO pieces from the groups.
2. Provide each group with index cards or sticky notes and markers.
3. Distribute the Clustering Criteria Handout containing a list of element properties (e.g., atomic mass, reactivity, state at room temperature, etc.).
4. Explain that each group will choose one or more criterion from the handout to create their own clustering system for the elements.
5. Instruct students to write element names on individual index cards or sticky notes based on their chosen criteria.
6. Allow groups to collaborate and place the index cards or sticky notes on a large poster board or classroom wall, forming clusters based on their criteria.
7. Encourage students to explain the reasoning behind their element placement within clusters, emphasizing the importance of justifying their choices.

4. Exploring the Periodic Table (10 minutes)

1. Distribute printed periodic tables, or project one for the class to see.
2. Instruct students to spend a few minutes examining the periodic table to become familiar with its layout and information.
3. Facilitate a brief class discussion to ensure that students understand atomic number, symbol, and the organization of elements into periods and groups.

5. Group Discussion (15 minutes)

1. Conduct a class discussion, with each group presenting their clusters and explaining their rationale.
2. Compare and contrast the clusters created by groups, and the machine learning model, and the actual organization of the periodic table.

6. Wrap-Up and Reflection (10 minutes)

1. Summarize the key points of the activity, highlighting that the periodic table organizes elements based on multiple properties and trends.
2. Discuss the challenges and benefits of clustering elements using different criteria.
3. Prompt students to reflect on what they learned about the periodic table, clustering, and the reasoning behind element grouping.
4. Conclude by reinforcing the idea that the periodic table is a dynamic tool for understanding and predicting the properties of elements.

Vocabulary/Definitions

classification: The act of categorizing items or data into groups or classes based on shared characteristics or attributes.

clustering: The process of grouping similar items or data points together based on shared characteristics or criteria, allowing for organization and analysis.

periodicity: The property of recurring patterns or trends in the periodic table, where elements exhibit similar behaviors or properties at regular intervals.

subjectivity: The quality of being influenced by personal opinions, interpretations, or perspectives, rather than being solely objective or based on concrete facts. In the context of clustering elements, subjectivity refers to the fact that different individuals or groups may create different element groupings based on their own chosen criteria.

Assessment

Pre-Activity Assessment

Vocab Review: Using hand signals (1-5 fingers, etc.), ask students about their familiarity with the terms in the vocabulary section, and clustering as a whole.

Activity Embedded (Formative) Assessment

Check-Ins: As students work, visit the groups and check in. Ask students to explain the reasoning behind the element placement within their clusters, emphasizing the importance of justifying their choices.

Post-Activity (Summative) Assessment

Written Reflection: Have students individually write up their reflections on what they learned about the periodic table, clustering, and the reasoning behind elemental grouping.

Activity Extensions

• Provide students with additional sets of clustering criteria and challenge them to create alternative clusterings for the elements.
• Have students research and present on specific element groups within the periodic table, explaining the scientific rationale behind their grouping.
• Have students explore real-life applications of clustering in chemistry and other scientific fields, discussing how it helps in data analysis and pattern recognition.
• Machine Learning Extension – Have students investigate how machine learning clusters anything, including images (e.g., optical character recognition [OCR] using digital pen displays and student writing samples).
