Quick Look
Grade Level: 6 (4-6)
Time Required: 45 minutes
Lesson Dependency: None
Subject Areas: Chemistry
NGSS Performance Expectations:
| 5-ESS3-1 |
Quick Look
Summary
Students develop their understanding of the effects of invisible air pollutants with a rubber band air test, a bean plant experiment and by exploring engineering roles related to air pollution. In an associated literacy activity, students develop visual literacy and write photograph captions. They learn how images are manipulated for a powerful effect and how a photograph can make the invisible (such as pollutants) visible. Note: You may want to set up the activities for Air Pollution unit, Lessons 2 and 3, simultaneously as they require extended data collection time and can share collection sites.Engineering Connection
Engineers design methods to measure invisible air pollutants and monitor air quality; they use these tools to measure emissions from vehicles and industry. For example, engineers design the equipment that is used when your car gets an emissions test. The equipment analyzes the substance discharged into the air by the internal combustion engine to determine whether the vehicle emissions include too many dangerous pollutants.
Learning Objectives
After this lesson, students should be able to:
- Identify the major types of invisible air pollutants.
- Describe how some invisible air pollutants affect our health.
- Describe how engineers interact with invisible air pollution.
Educational Standards
Each TeachEngineering lesson or activity is correlated to one or more K-12 science,
technology, engineering or math (STEM) educational standards.
All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN),
a project of D2L (www.achievementstandards.org).
In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics;
within type by subtype, then by grade, etc.
Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.
All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).
In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.
NGSS: Next Generation Science Standards - Science
| NGSS Performance Expectation | ||
|---|---|---|
|
5-ESS3-1. Obtain and combine information about ways individual communities use science ideas to protect the Earth's resources and environment. (Grade 5) Do you agree with this alignment? |
||
| Click to view other curriculum aligned to this Performance Expectation | ||
| This lesson focuses on the following Three Dimensional Learning aspects of NGSS: | ||
| Science & Engineering Practices | Disciplinary Core Ideas | Crosscutting Concepts |
| Obtain and combine information from books and/or other reliable media to explain phenomena or solutions to a design problem. Alignment agreement: | Human activities in agriculture, industry, and everyday life have had major effects on the land, vegetation, streams, ocean, air, and even outer space. But individuals and communities are doing things to help protect Earth's resources and environments. Alignment agreement: | A system can be described in terms of its components and their interactions. Alignment agreement: Science findings are limited to questions that can be answered with empirical evidence.Alignment agreement: |
Common Core State Standards - Math
-
Fluently add, subtract, multiply, and divide multi-digit decimals using the standard algorithm for each operation.
(Grade
6)
More Details
Do you agree with this alignment?
-
Find a percent of a quantity as a rate per 100 (e.g., 30% of a quantity means 30/100 times the quantity); solve problems involving finding the whole, given a part and the percent.
(Grade
6)
More Details
Do you agree with this alignment?
International Technology and Engineering Educators Association - Technology
-
The management of waste produced by technological systems is an important societal issue.
(Grades
6 -
8)
More Details
Do you agree with this alignment?
-
Analyze how the creation and use of technologies consumes renewable and non-renewable resources and creates waste.
(Grades
6 -
8)
More Details
Do you agree with this alignment?
State Standards
Colorado - Science
-
Identify evidence suggesting that atoms form into molecules with different properties than their components
(Grade
6)
More Details
Do you agree with this alignment?
-
Develop, communicate, and justify an evidence-based explanation about how ecosystems interact with and impact the global environment
(Grade
6)
More Details
Do you agree with this alignment?
Worksheets and Attachments
Visit [www.teachengineering.org/lessons/view/cub_air_lesson03] to print or download.Introduction/Motivation
Ask students to recall a visit to a gas station: Have they ever pumped the gas themselves or helped someone else do it? Have they ever taken a close look at the gas pump handle? Have they ever noticed that when they travel to other states or countries the pump nozzle may appear different? In Colorado (and many other places), the pump handles are equipped with a "rubber collar," designed by an engineer to prevent volatile organic compounds (VOCs, such as benzene) from escaping into the air while gas is pumped. This collar protects you from serious health effects that may result from inhaling fumes and also protects the environment from the smog caused by VOCs.
Create an idea web: Ask students to brainstorm a list of invisible pollutants. What effects do these pollutants have on us and our environment? What are some possible solutions for reducing these types of pollutants? (Refer students to the Common Air Pollutants Reference Sheet or see the U.S. Environmental Protection Agency (EPA) Air Trends website at: www.epa.gov/airtrends/.
Lesson Background and Concepts for Teachers
The atmosphere is almost completely composed of invisible gaseous substances. Most major air pollutants are also invisible, meaning you cannot see or smell them. However, when large amounts of them are concentrated in areas such as cities, they can be seen as smog. Invisible air pollutants are among the most dangerous to our health. Refer to the associated activity What's Hiding in the Air? to develop students' understanding of the effects of invisible air pollutants with a rubber band air test and a bean plant experiment. Then follow with the second associated activity Visual Literacy: Tears in (Acid) Rain to help students learn how images are manipulated for a powerful effect and how a photograph can make the invisible (pollutants that form acid rain) visible (through the damage they cause).
The EPA set national air quality standards for six principal air pollutants (also referred to as criteria pollutants): carbon monoxide (CO), lead (Pb), nitrogen dioxide (NO2), sulfur dioxide (SO2), ozone (O3) and particulate matter (PM). Four of these pollutants (CO, Pb, NO2 and SO2) result primarily from direct emissions from a variety of everyday sources. Particulate matter results from direct emissions, but is also commonly formed when emissions of nitrogen oxides (NOx), sulfur oxides (SOx), ammonia, organic compounds and other gases react in the atmosphere. Ozone is not directly emitted, but is formed when NOx and volatile organic compounds (VOCs) react in the presence of sunlight.
Associated Activities
- What's Hiding in the Air? - Students develop their understanding of the effects of invisible air pollutants with a rubber band air test and a bean plant experiment.
- Visual Literacy: Tears in Acid Rain - In this literacy activity, students develop visual literacy and write photograph captions. They learn how images are manipulated for a powerful effect and how a photograph can make the invisible (pollutants that form acid rain) visible (through the damage they cause).
Lesson Closure
Ask students if they would like to add anything new to the idea web. Assign the Carbon Monoxide Emissions Worksheet as homework.
Vocabulary/Definitions
carbon monoxide: A colorless, odorless and poisonous gas made of one carbon atom and one oxygen atom. Abbreviated as CO.
invisible pollutant: Air pollution that cannot be smelled or seen with the naked eye.
ozone: Ground-level ozone is the principal component of smog, created from chemical reactions of pollutants, VOCs, and NOx. Abbreviated as O3.
volatile organic compound: An organic chemical containing carbon that escapes into the air easily. Abbreviated as VOC. VOCs react with sunlight to produce ground-level ozone. VOCs are the most common type of indoor pollutant.
Assessment
Pre-Lesson Assessment
Discussion Topic: Ask students to recall a visit to a gas station. Have they ever pumped gas themselves or helped someone else do it? Have they ever taken a close look at the gas pump handle? Have they ever noticed that when they travel to other locations the pump nozzle may appear different? Why?
Post-Introduction Assessment
Idea Web: Ask students to brainstorm a list of invisible pollutants. What effects do these pollutants have on us and our environment? What are possible solutions for reducing these types of pollutants?
Lesson Summary Assessment
Idea Web Revisited: Ask students if they would like to add anything new to their idea web.
Informative Flyer: Have students create a flyer to inform other students, the school or their community about the presence of visible and invisible pollutants in the air. Include some of the ideas they generated in the idea web. Display these flyers in the classroom or the school's common area.
Homework
Worksheet: Assign students to complete the Carbon Monoxide Emissions Worksheet. Discuss findings during the next class period, paying particular attention to questions 3 and 6.
Lesson Extension Activities
Take a field trip to a vehicle emissions testing site. Or, invite a speaker from a vehicle emissions testing site to speak to your class about how they measure the invisible pollutants from vehicles. What determines whether or not a car passes the inspection?
Subscribe
Get the inside scoop on all things TeachEngineering such as new site features, curriculum updates, video releases, and more by signing up for our newsletter!More Curriculum Like This
Students are introduced to the concepts of air pollution, air quality, and climate change. The three lesson parts (including the associated activities) focus on the prerequisites for understanding air pollution. First, students use M&M® candies to create pie graphs that express their understanding o...
Looking at transportation and the environment, students learn that some human-made creations, such as vehicles, can harm the natural environment. They also learn about alternative fuels and vehicles designed by engineers to minimize pollution. The associated hands-on activity gives students a chance...
Students are introduced to the concepts of air pollution and technologies that engineers have developed to reduce air pollution. They develop an understanding of visible air pollutants with an incomplete combustion demonstration, a "smog in a jar" demonstration, construction of simple particulate ma...
References
Air Trends. Updated May 4, 2004. U.S. Environmental Protection Agency. Accessed July 13, 2004. www.epa.gov/airtrends.
The Plain English Guide to the Clean Air Act, The Common Air Pollutants. Updated May 13, 2002. U.S. Environmental Protection Agency, EPA-OAQPS. Accessed July 13, 2004. www.epa.gov.
